purpose¶

to create grid-based layouts, obviously

historical note

creating this kind of layout has been a challenging task in the past

the <table> tag has long been overused to address that sort of needs
twitter’s bootstrap has been used for this too at some point
do not use these tools for that in 202x !

ex1 - proportional columns¶

next snippet demontrates:

a proportional grid of [3 rows ⨉ 4 columns]
with 4 areas defined, based on that tiling header, main, sidebar, and footer
and 4 <div>s that are mapped on these areas e.g. grid-area: header

all this in one property:

let grid_html = `<div class="container">
  <div id="item-a">
    the header<br>blabla
  </div>
  <div id="item-b">
    main area<br>blabla<br>blabla
  </div>
  <div id="item-c">
    side bar<br>blabla
  </div>
  <div id="item-d">
    a footer<br>blabla
  </div>
</div>`

let grid1_css = `.container {
  display: grid;
  grid-template-columns:
    1fr 1fr 1fr 1fr;
  grid-template-areas:
    "header header header header"
    "main   main   .      sidebar"
    "footer footer footer sidebar";
}

#item-a {
    grid-area: header;
    background-color: #ffba5a;
}
#item-b {
    grid-area: main;
    background-color: #3282b8;
}
#item-c {
    grid-area: sidebar;
    background-color: #db3056;
}
#item-d {
    grid-area: footer;
    background-color: #7fa998;
}`
await tools.sample_from_strings({html: grid_html, css: grid1_css}, {id: 'grid-1', start_with: 'css', height: "16em"})

ex2 - partially fixed columns¶

mostly the same, but :

we can specify fixed size for some columns
only change is to replace
- grid-template-columns: 1fr 1fr 1fr 1fr with
- grid-template-columns: 100px 1fr 5% 1fr;

and now

the first column has a fixed size
the third column has a size proportional to the page width
and columns 2 and 4 equally share whatever is left in width

let grid2_css = `.container {
  display: grid;
  grid-template-columns:
    100px 1fr 5% 1fr;
  grid-template-areas:
    "header header header header"
    "main   main   .      sidebar"
    "footer footer footer footer";
}

#item-a {
    grid-area: header;
    background-color: #ffba5a;
}
#item-b {
    grid-area: main;
    background-color: #3282b8;
}
#item-c {
    grid-area: sidebar;
    background-color: #db3056;
}
#item-d {
    grid-area: footer;
    background-color: #7fa998;
}`

await tools.sample_from_strings({html: grid_html, css: grid2_css}, {id: 'grid-2', start_with: 'css', height: "16em"})

ex3 - on rows too¶

in the previous examples :

we have not imposed anything on the height of the result
each box gets its height based on its content

it is also possible - although less often needed

to fix a height globally and arrange the rows accordingly
only change is to add on the grid:
- height: 100vh to say we want to use all viewport height
- grid-template-rows: 50px 1fr 100px;
  which specifies how to use vertical space

width and height do not behave quite the same !

you may not have realized it yet, but because in Western languages we read from left to right and top to bottom, the horizontal and vertical directions are not quite symmetrical when it comes to page layout

think of the width of a document as something fixed (by the device screen size), but its height depends on the content...

this is why setting grid-template-rows is less often needed than setting grid-template-columns

let grid3_css = `.container {
  display: grid;
  grid-template-columns: 1fr 1fr 1fr 1fr;
  grid-template-areas:
    "header header header header"
    "main main . sidebar"
    "footer footer footer footer";
  grid-template-rows: 50px 1fr 100px;
  height: 100vh;
}

#item-a {
    grid-area: header;
    background-color: #ffba5a;
}
#item-b {
    grid-area: main;
    background-color: #3282b8;
}
#item-c {
    grid-area: sidebar;
    background-color: #db3056;
}
#item-d {
    grid-area: footer;
    background-color: #7fa998;
}
`
await tools.sample_from_strings({html: grid_html, css: grid3_css}, {start_with: 'css', height: "16em"})

assignment: the css-tricks page¶

browse quickly - but entirely - the very good introduction to grids that can be found on css-tricks.com so as to get a good grip of what’s achievable

optional game

you may also complete this game https://cssgridgarden.com/ at home if you feel like it
